JINDAL



Jindal Rolling Mills Ltd is one of the leading manufacturing companies in India and has redefined the level of construction by manufacturing a comprehensive range of TMT Bars. Jindal manufactures and suppliers of structural steel and reinforcement bars. The product range of the company comprises joints, angles, TMT Bars, Channels and Flats. Structural steel items are manufactured under the brand name of Jindal, whereas TMT Bars are under the name Jindal TMT Bars. Jindal TMT Bars are designed by talented engineers and are acknowledged for their high tensile strength & earthquake-resistant design. Jindal TMT steel bars are preferred for their reliability, durability and can be obtained at pocket-friendly prices.

Jindal TMT Bars Production Process

1. Furnace
2. CCM Ladle (Continuous Casting Machine)
3. Reheating
4. Rolling Mill
5. Cooling Bed
6. Stocking
7. Dispatch

Specifications Of Jindal Steel TMT Bars

Jindal TMT Bar Sizes- 8mm, 10mm, 12mm, 16mm, 20mm, 25mm and 32mm.

Chemical Properties Of Jindal TMT Steel Bars

Chemical Composition Elements Of Jindal TMT Steel Bars- Carbon, Sulphur, Phosphorous, S+P, Carbon equivalent elements are added up to the range from a maximum 0.030% to 0.42%. Jindal TMT Bars reduce the combined level of these impurities up to 0.075% as per the latest BIS specifications.

Mechanical Properties Of Jindal TMT Steel Bars

Jindal TMT 500HD describes high ductility rebars which observe the efficiency of earthquake shocks and ensures the best resistance against seismic shocks.

• The Yield Strength value as per IS:1786-2008 for Fe 500 is 500 N/mm2 and Fe 500HD is 500 N/mm2.
• The Tensile Strength value for Fe 500 is 8% more than the actual YS but not less than 545 N/mm2 and for Fe 500HD is 0% more than the actual YS but not less than 565.
• Elongation value for Fe 500 is 12% and Fe 500D is 16%.
• Uniform Elongation factor for both Fe 500 & Fe 500HD is same i.e 0.5% minimum value.
• For Fe 500, the rebend test is Up To 10 Mm-5D Over 10 Mm7D and for Fe 500HD is up To 10mm-4 Over 10 Mm-6D.

Advantages Of Jindal TMT Steel Bars

Ductility

Ductility is the ability of a material to plastically deform and adapt while being stressed with a tensile load. When a piece of ductile material is pulled, before rupture (breaking apart), it is well deformed, changes its shape to adapt to the stress of Jindal TMT Bars.

Easy Weldability

Due to the low carbon content in Jindal TMT bars, it has a great weldability factor and is sufficient to use it in construction. It can be easily butt-welded, lap- welded and manual arc welding can also be done without preheating the materials.

Corrosion Resistance

Due to its uniform and unique microstructure and absence of residual stress, Jindal TMT bars have high corrosion resistance.

Higher Strength

Jindal TMT Bars are made from high quenching process and self tempered process, due to this factor, it enhances the high strength in TMT bars.

Earthquake Resistance

Jindal TMT 500HD Rebars are specially designed for earthquake resistance factor due to the higher strength and ductility. It has more Strength to sustain fire, it would not distort up to the temperature of 500-600 Cº.

Bond Strength With Concrete

Due to critically and uniform designed rib patterns, rib gives more strong bonding strength with concrete.

High Bendability

Jindal TMT Bars can be customized at any of the shapes in spite of having high strength due to inherent microstructure with pearlier core and soft ferrite core. By this the bendability factor in Jindal TMT Bars is high.

Features Of Jindal TMT Bars

• Robust Construction
• Ruggedness
• Excellent Strength
• Easy To Use

Applications Of Using Jindal Steel TMT Bars

Jindal TMT Bars are one of the best Brands that are mainly used in the construction of Houses, Bridges, Buildings, Dams, Industrial Projects, Higher Constructive Projects Etc.

To have ideal construction for the consumers with a good lifetime, they need to prefer Jindal Steel TMT Bars. Because these bars are having greater stability, weldability, bendability, and high strength factors. Considering all these main points, Steeloncall.com is going to provide the Jindal Steel TMT bars for the consumers at affordable prices. All these Jindal TMT prices are provided in a cost-effective manner for everyone.
